1. Map sensitivity of bioregion delineation to clustering method using map_bioregDiff()

In the sections below we use map_bioregDiff() to assess how much our four clustering algorithms disagree (a sensitivity check). Here we treat the various cluster maps generated with map_bioreg() (k-means, PAM, hierarchical and GMM) as a sensitivity analysis. By feeding all four algorithm outputs into map_bioregDiff(), we quantify where and how much those methods disagree. This shows which areas are robust to algorithm choice and which are method‐dependent.

Change-metric options in map_bioregDiff() include (approach argument):

  • difference_count: counts how many times a cell’s label deviates from the first layer.
  • shannon_entropy: Shannon entropy of the label sequence, a measure of within-cell diversity.
  • stability: proportion of layers in which the label is unchanged (1 = always stable, 0 = always different).
  • transition_frequency: total number of label flips between consecutive layers, showing how often change occurs.
  • weighted_change_index: cumulative change weighted by a dissimilarity matrix so rare or large transitions score higher.
  • all (default): returns a five-layer SpatRaster containing every metric.
# Get current nn rasters
# current_nn = c(bioreg_current$nn$current$kmeans_algn_current,
#              bioreg_current$nn$current$pam_algn_current,
#              bioreg_current$nn$current$hclust_algn_current,
#              bioreg_current$nn$current$gmm_algn_current)
names(current_nn)
#> [1] "kmeans_algn_current" "pam_algn_current"    "hclust_algn_current"
#> [4] "gmm_algn_current"

# Run `map_bioregDiff`
# 'approach', specifies which metric to compute:
sens_bioregDiff = map_bioregDiff(
  current_nn,
  approach = "all"
)

# Inspect the output layers
sens_bioregDiff
#> class       : SpatRaster
#> size        : 25, 32, 5  (nrow, ncol, nlyr)
#> resolution  : 0.5, 0.4999984  (x, y)
#> extent      : 16.75, 32.75, -34.75, -22.25004  (xmin, xmax, ymin, ymax)
#> coord. ref. : lon/lat WGS 84 (EPSG:4326)
#> source(s)   : memory
#> names       : Differ~_Count, Shanno~ntropy, Stability, Transi~quency, Weight~_Index
#> min values  :             0,      0.000000,         0,             0,    0.01694915
#> max values  :             3,      1.039721,         1,             3,    2.99011299

# Crop to our study area and prepare for plotting
mask_sens_bioregDiff = terra::mask(
  terra::resample(sens_bioregDiff, grid_masked, method = "near"),
  grid_masked
)

# Quick visual QC in a 3×2 layout
old_par = par(mfrow = c(3, 2), mar = c(1, 1, 1, 5))
titles = c("Difference count", "Shannon entropy", "Stability",
           "Transition frequency", "Weighted change index")

for (i in seq_along(titles)) {
  plot(mask_sens_bioregDiff[[i]],
       col      = viridis(100, direction = -1),
       colNA    = NA,
       axes     = FALSE,
       main     = titles[i],
       cex.main = 0.8)
  plot(terra::vect(rsa), add = TRUE, border = "black", lwd = 0.4)
}
par(old_par)

2. Map bioregion sensitivity to future change using map_bioregDiff()

Here we use map_bioregDiff() to track how the hierarchical‐cluster map itself changes under three future climate scenarios. Focusing solely on the hierarchical solution we map bioregion change across time. First we stack the hierarchical clusters for today, 2030, 2040 and 2050, run map_bioregDiff() on that series, and highlight how bioregions shift under these future climate projections. In this way we isolate climate-driven reorganization in the hierarchical map itself.

# 1. Build a multi‐layer SpatRaster of hierarchical clusters for each scenario
# Create SpatRast
# future_hclt = c(bioreg_future$nn$current$hclust_current,
#              bioreg_future$nn$`2030`$hclust_2030,
#              bioreg_future$nn$`2040`$hclust_2040,
#              bioreg_future$nn$`2050`$hclust_2050)
names(future_hclt)
#> [1] "hclust_current" "hclust_2030"    "hclust_2040"    "hclust_2050"

# 2. Compute change metrics across those four layers
future_bioregDiff = map_bioregDiff(future_hclt, approach = "all")

# 3. Mask to your RSA boundary (assuming 'grid_masked' is your template)
mask_future_bioregDiff = terra::mask(
  terra::resample(future_bioregDiff, grid_masked, method = "near"),
  grid_masked
)

# 4. Plot all five metrics in a 3×2 panel
old_par = par(mfrow = c(3, 2), mar = c(1, 1, 1, 5))
titles = c(
  "Difference count",
  "Shannon entropy",
  "Stability",
  "Transition frequency",
  "Weighted change index"
)
for (i in seq_along(titles)) {
  plot(
    mask_future_bioregDiff[[i]],
    # col      = viridisLite::turbo(100),
    col      = viridis(100, direction = -1),
    colNA    = NA,
    axes     = FALSE,
    main     = titles[i],
    cex.main = 0.8
  )
  plot(terra::vect(rsa), add = TRUE, border = "black", lwd = 0.4)
}
par(old_par)
